Specifikim
Parametri i funksionit | |
formal Battery Energy | 3900wh |
formal kapacitet | 65Ah |
formal tension | 60V |
Rezistenca e brendshme | ≤22mΩ |
Jeta e ciklit | > 6000 |
Muaj Shkarkimi Vetë | <3% |
Të dhënat e ngarkimit | |
Tensioni Normal i Ngarkesës DC | 54.75 ± 1Vdc |
Modaliteti i karikimit | 0.2C në 54.75V, pastaj 54.75V, rryma e ngarkimit në 0.02C (CC/CV) |
Rryma e rekomanduar e karikuesit | ≤50A |
Lejohet Maks. Karikimi aktual | 50Adc |
Ngarkoni tensionin e ndërprerjes | 54.75 ± 1Vdc |
Të dhënat e shkarkimit | |
Rryma e vazhdueshme e shkarkimit | 50A |
Lejohet Maks. rryma e shkarkimit | 100A (opsioni:100Adc) |
Shkalla e tensionit të shkarkimit DC | 37.5V-54.75Vdc |
Gjendja e punes | |
Temperatura e ngarkimit | 0 ℃ në 45 ℃ (32 ℉ në 113) @60 ± 25% Lagështia relative |
Temperatura e shkarkimit | -20 ℃ në 60 ℃ (-4 ℉ në 140) @60 ± 25% Lagështia relative |
Temperatura e ruajtjes | 0 ℃ në 40 ℃ (32 ℉ në 104) @60 ± 25% Lagështia relative |
Niveli i mbrojtjes së rrethimit | IP67 |
Features
1.Rechargeable battery
2.Use of Iron(Fe) as a cathode material
3.Higher discharge current
4.Do not explode under extreme conditions and weight less
Përparësitë
1.Extremely high rate capability
2.Safe lithium battery
3.Good storage characteristics
4.Good high temp performance
5.Long cycle life to 2000 times
6.High capacity & light weight
7.Environmentally friendly
8.No memory effect
We can provide you with customized services
Customized 7.4V-12V-24V-36V-48V-52V-60V-72V...LITHIUM BATTERY PACK
The capacity and dimension can customize according to your request:
1. Madhësia e personalizuar e baterisë dhe materiali i guaskës
2. BMS e personalizuar e ngarkimit dhe shkarkimit të rrymës
3. Spinën dhe prizën e personalizuar të lidhjes, tela lidhës
AIN Paketat e Baterive Lithium Zbatimet Kryesore | |
Zbatime elektrike të shtytjes | bateria e ndezjes së motorit; Makinë me Shpejtësi të Ulët; robotë intelektualë; biçikletë elektrike / motor / skuter; karrocë golfi / karroca / makinë për ndonjë gjë; vegla elektrike. |
Ruajtja e energjisë | sistemin e energjisë diellore dhe të erës; rrjeti i ndezjes / fikjes së qytetit; komuniteti dhe familja, RV Caravan, jahte Detare. |
Sistemi rezervë dhe UPS | Telecommute base, CATV-system, computer server center, medical instrument, military equipment. |
Aplikime të tjera | siguri dhe elektronikë; POS celular, drita minerare / pishtari / drita LED / drita emergjente. |
